Electromagnetic Analysis

Electromagnetic Analysis Bench around the Tektronix RSA607A Real-Time Spectrum Analyzer

30

Equipment :

  • Tektronix real-time spectrum analyser RSA607A: 9 kHz to 7.5 GHz frequency range, 40 MHz capture bandwidth, 0.2dB amplitude accuracy, 100 µs minimum signal duration with 100% intercept probability
  • Many EM probes: H and B types, local or global precision, different tip shapes
  • ProScan III: Prior Scientific 3-axis motion table, 1µm resolution
